Audio Technica | ATM610a | Handheld Hypercardioid Dynamic Microphone

OVERVIEW

Tuned for clear, detailed, extended-range reproduction of lead and backup vocals, the premier Artist Series dynamic vocal mic is equipped with a rare-earth magnet, a tight hypercardioid polar pattern and multi-stage grille design. The microphone features a newly designed internal shock mount design to reduce handling and stage noise.



FEATURES

• Hypercardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source
•  Durable performance for professional applications
•  Newly designed superior internal shock mounting reduces handling and stage noise
•  Rare-earth magnet for articulate vocal reproduction
•  Multi-stage grille design offers excellent protection against plosives and sibilance without compromising high-frequency clarity
•  Quiet-Flex™ stand clamp provides silent, flexible microphone positioning
•  Corrosion-resistant contacts from gold-plated XLRM-type connector
•  Rugged, all-metal design and construction for years of trouble-free use

SPECIFICATIONS



Element	Dynamic
Polar Pattern	Hypercardioid
Frequency Response	40-16,000 Hz
Open Circuit Sensitivity	55 dB (1.7 mV) re 1V at 1 Pa
Impedance	300 ohms
Weight	270 g
Dimensions	170.0 mm long, 48 mm diameter
Output Connector	Integral 3-pin XLRM-type
Accessories	AT8470 Quiet-Flex® stand clamp for 5/8″ threaded stands; 5/8″ to 3/8″ threaded adapter; soft protective pouch
Polar Pattern
Frequency Response
